90 Deg 5D Bend Elbow Butt Weld Duplex 2205 Pipe Fittings ASTM A815 WPS S31803
| 原产地 | CHINA |
|---|---|
| 品牌名称 | Shangle |
| 认证 | ISO9001 |
| 产品型号 | stainless steel pipe fittings |
| 最小订货量 | MOQ500kg |
| 价格 | Negotiable |
| 包装 | In wooded cases or pallets,or as for clients requirement |
| 交货周期 | 7-15 working days after receiving payment |
| 付款条款 | L/C, T/T |
| 供货能力 | 9999 |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
x产品详情
| Port | Ningbo | Size | 1/8”NB To 4”NB (Socketweld & Screwed-Threaded) |
|---|---|---|---|
| Type | Screwed-Threaded Fittings | Package | Seaworthy Standard Package |
| Price Terms | FOB,CIF,CFR,EXW | Shape | Equal |
| Connection | Female/Male | Degree | 45°，90°，180° |
产品说明
Duplex Steel 2205 Fittings, ASTM A815 WP-S S31803 1.4462 Butt Weld 90 Deg 5D Elbow B16.9
Wenzhou Shangle Steel Co., Ltd. (Shangle) founded in 2017,is a comprehensive company integrating industry and trade.As a leading supplier of stainless steel products in Wenzhou, it has a wide range of products in stock that have been rigorously tested and are ready to be shipped.
Description :
ASTM A815 WPS31803 Duplex Steel Pipe Fittings can be welded or seamless. These duplex steel fittings are made up of a corrosion resistant, strong and high temperature capable duplex steel material. The welded fittings can range from 1/8” to 48” in nominal size and the seamless fittings range from 1/8” to 24”. ASTM A815 WPS31803 Duplex Stainless Steel Buttweld Fittings are the most common form of fittings. ASME A815 WP-S S31803 Duplex Steel Butt Weld Pipe Fittings contain a combination of austenitic and ferrite stainless steel which has excellent corrosion & oxidation resistance, high tensile strength and excellent mechanical properties.
Chemical Composition:
| C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
Mechanical Properties:
| Tensile Strength, ksi | 90 min |
| 0.2% Yield Strength, ksi | 65 min |
| Elongation, % | 25 min |
| Hardness [HRC] | 293 max |
Specifications:
| Specifications | ASTM A815, ASME SA815 |
| Size Range | Welded: 1/8” – 48” Seamless: 1/8” – 24” |
| Connection | Welding |
| Radius of Bending | R=3D, 1D, 8D, 10D, 5D, 2D, Custom MSS Sp-43, 6D |
| Manufacturing Process | Forge, Press, Cast, Push etc. |
| Thickness | SCH10 - SCH XXS |
| Pressure Ratings | 2000#, 150#, 6000#, 3000#, 9000# |
| End Connections: | socket weld and Threaded |
| Type | Tee, Elbows, Pipe Cap, Stub End, Crosses, Pipe Bend, Reducers |
| Dimensions | ASME B16.28, BS4504, MSS-SP-43, ASME/ANSI B16.9, BS1560, BS4504, BS10 |
Applications:
Food Processing
Pharmaceuticals
Chemical Processing
Piping & Tubing Systems
Oil & Gas Refineries
Petrochemicals
Sugar Mills & Distilleries
Ship Building Systems
Cement Industries
Fertilizers
Automation
Detail Images:
